AGS10 TVOC Air Quality Gas Sensor Module

AGS10 TVOC Air Quality Gas Sensor Module For Arduino（I2C MEMS/Replace AGS02MA）

Description

AGS10 is a MEMS TVOC sensor that uses digital I2C signal output. Equipped with dedicated digital module acquisition technology and gas sensing technology, the product has high reliability and excellent long-term stability, while also featuring low power consumption, high sensitivity, fast response, low cost,and simple driving circuit.

Specification

• Working voltage. 3.0-6.0 V
• Typical power: 75mW
• Sampling period:≥2s
• Interface speed: I2C slave mode (≤15kHz)
• Preheating time:≥120s
• Working temperature: 0-50℃
• Working humidity: 0-95% RH
• Service life:>5 years (25 °C, in clean air)
• Output unit: ppb
• Measurement range:0-99999 ppb
• Typical accuracy (25℃/50% RH): 25% reading
• Standard test gas: ethanol
• Module size: 15 .20 * 10. 50mm
