DC-DC Boost Module 0.9-5V To 5V-9V with different output current

DC-DC Boost Module 0.9-5V To 5V-9V-480MA/600MA/1A/1.2A/2A OR USB Output Voltage Step UP Lithium Battery Module For Phone Camera

♦ 0.9-5V to 5V 480MA

DESCRIPTION

• Input voltage 0.9~ 5V,output 5V
• Maximum output current: 480 MA,
• Start Voltage 0.8V, Output Current 7MA
• INPUT 1-1.5V,OUTPUT 5V 40-100MA;
• INPUT 1.5-2V,OUTPUT 5V 100-150MA;
• INPUT 2-3V,OUTPUT 5V 150-380MA;
• INPUT above 3V, OUTPUT 5V 380-480MA;
• DC-DC Boost module working frequency 150KHZ. efficiency <85%(Recommended high eficiency version).
• 2. 54mm pin pitch.
• Excluding Pin Size 11mm X 10 5mm x 7.5mm(Very smal).

APPLICATIONS

• Battery powered equipment
• Wireless Module ,NRF24L01 CC1101 CC2500 etc.
• Development Board,FPGA/CPLD UNO MEGA2560 PRO MINI 8051 C8051 AVR STC etc
• Camera, Video camera
• VCR
• PDA
• LED Lighting
• Wireless communication equipment
• MP3/MP4 player
• Audio equipment

♦ 1-5V to 5V 600MA

FEATURES

1.input any DC voltage of 1V~5V, output 5V DC voltage is stable, the input to the output current of 500~600MA with two AA batteries, a single AA battery power supply output current 200ma about for mobile phones camera, single-chip, digital products supply.
2.high conversion efficiency, up to 96%
3.ultra-small size, installed in a variety of small equipment
4.with working lights

PARAMETERS

1.Input voltage:1V~5V
2.Output voltage: 5V
3.Output Current: 600mA
4.PCB size: 17.55mm*25.22mm*5. 85 mm
5.En bloc Size: 17.55*32 53*83mm

♦ 5V 600MA Boost Blue

INTRODUCTION

1. This module uses high-performance imported chip, the performance is better than the general module.
2. Input 0.9V ~ 5V any DC voltage, can be stable output 5V DC voltage, with a single AA battery can output up to 200 ~ 300MA current, two AA batteries can output 500~600MA of current, can Power your phone, camera, microcontroller and digital products.
3. Industrial temperature range: -40℃~+85℃
4. High conversion efficiency, up to 96%
5. With USB female base, widely used
6. Ultra-small size (PCB board 35mm * 16mm), with a variety of small equipment installed
7. With work light

♦ 5V 600MA Boost Green

DESCRIPTION

1. This module uses imported high-performance chip, the performance is superior to the general module.
2. Enter any 0.9V ~ 5V DC voltage of 5V DC output voltage can be stable, with a single AA battery can deliver up to 200 ~ 300MA current, two AA batteries to output 500~600MA of current, for your phone (iphone temporarily can not), camera, microcontroller and digital products supply
3. Industrial Temperature Range:prefix= st1 ns = “urn: schemas-microsoft-com: office: smarttags” -40 Celsius ~ + 85 Celsius.
4. High conversion efficiency, up to 96%
5. With USB female seat, wide range of uses.
6. The ultra-small size (PCB board 25mm * 18mm), with the installation of a variety of small equipment inside.
7. With working lights.

FEATURE

• Module Properties: non-isolated step- up module (BOOST)
• input voltage: 1-5V
• Output voltage: 5.1-5.2V
• Output Current: Rated 1A-1.5A (single lithium input), the maximum 1.5A (single lithium input)
• Efficiency: Up to 96% (the higher the input voltage, the higher the fficiency)
• Switching frequency: 500KHz
• Output ripple: 30mV (MAX) 20M bandwidth (input 4V output 5.1V 1A)
• Voltage indication: LED lights with load (input voltage less than 2.7V LED indicator off)
• Operating Temperature: Industrial (-40℃ to +85℃)
• Full load temperature rise: 30℃
• Quiescent Current: 130uA
• Load regulation: &plusmn: 1%
• Voltage regulation: &plusmn; 0.5%
• Dynamic response speed: 5% 200us
• Short circuit protection: None (Please use the lithium battery with protection)
• Input Reverse Polarity Protection: None
• Connection: Welding
• Input: IN + Postive, IN-Negative
• Output: USB Output

♦ 1-5V to 5V 1A (1000mA)

DESCRIPTION

1. Module Properties: non-isolated step-up module (BOOST)
2. Input voltage: 1-5V
3. Output voltage: 5.1~5.2V
4. Output Current: Rated 1A~1.5A (Single lithium battery input)
5. Conversion eficiency: up to 96% ( input voltage, the higher the eficiency )
6. Switching Frequency: 500KHz
7. Output ripple: 30mV (Max) 20M Bandwidth ( Input 4V, Output 5.1V 1A)
8. Voltage indication: LED lights with a load (input voltage is lower than 2.7V LED indicator off )
9. Operating temperature: Industrial grade (-40 Celsius to +85 Celsius )
10. Full load temperature rise: 30 Celsius
11. Quiescent Current: 130uA
12. Load regulation:±1%
13. Voltage regulation:±0.5%
14. Dynamic response speed: 5% 200uS
15. Short circuit protection: None
16.Input Reverse Polarity Protection: None
17.Wiring: Welding

♦ 2-5V to 5V 1200MA

INTRODUCTION

• Condition: New
• Inpute voltage: 2.0V 5.0V
• No load output voltage: 5.1V +0.1V
• Transfer efficiency: 90%(max) 85%(average)
• If charge for iPhone 5, voltage should over 3V
• Input2v ~ 5 v dc voltage, can stable output 5v dc voltage
• Input with two AA batteries can output current of 1000 ma,
• single section lithium batteries can be output current of 1200 mA
• Chargeing for mobile phone, camera, single chip microcomputer, digital products With USB, wide range of uses
• 3.7V up to 5V1 1A typical application efficiency reached 87%
• Ultra small size
• With indicator light, and set aside to identify the installation position of resistance
• Color is shown as pictures

♦ 3-5V to 5-9V 2000mA

INTRODUCTION

Small size design,high power,Output Current 2000MA, high efficiency, average efficiency can up to 94%,with under voltage indicator function.

Module Features

• Note:Output voltage must be higher than Input Voltage
• Input Voltage:2-6V(less than 3V,output power cut down)
• Output Voltage:3.3V-9V adjustable(Input voltage must less than output voltage)
• Output Current:Rated 2000mA (2.8V-3V input, 5V output, 1500MA output,(single lithium battery higher 2600MAH input,5V output, output current can up to 2000MA)
• Note:Output voltage higher than 6V,Please connect power first,then connect load line
• Conversion eficiency:the average is 90% (the higher the input voltage, the higher the efficiency)
• Output ripple:50mV (MAX)
• Operating temperature:Industrial grade (-40°C to +85°C)
• Full load temperature rise:20°C
• static Current: 130uA(No LED)
• Load regulation:±1%
• Voltage regulation rate:±0 .5%
