Siemens 6ES7 223-1BL32-0XB0 Digital I/O Expansion Module(Price Negotiating!)

Item: Siemens SIMATIC S7-200 Digital I/O Expansion Module (Part Number: 6ES7 223-1BL32-0XB0)

Enhance your Siemens S7-200 automation system with this digital I/O expansion module. The 6ES7 223-1BL32-0XB0 provides an additional 16 digital inputs and 16 digital outputs, making it ideal for expanding your PLC’s control capabilities. This module is designed for 24V DC operation and offers reliable performance in a wide range of industrial applications.

Key Features:

• 16 Digital Inputs (24V DC) with configurable input signal delay
• 16 Digital Outputs (24V DC, 0.5A per output) with short-circuit protection
• Compatible with Siemens S7-200 PLC series
• Transistor outputs (sink/source) for versatile use with various sensors and actuators
• Compact design for easy DIN rail or panel mounting
• Diagnostic LEDs for status monitoring of inputs and outputs
• IP20 protection rating, suitable for industrial environments
• Operating temperature range: 0°C to +55°C

The Siemens 6ES7 223-1BL32-0XB0 is a digital expansion module from the SIMATIC S7-200 series. It is specifically designed to extend the digital I/O capabilities of the S7-200 programmable logic controllers (PLCs).

Here are the detailed technical specifications:

General Specifications:

• Product Type: SIMATIC S7-200 Digital Expansion Module
• Order Number: 6ES7 223-1BL32-0XB0
• Series: S7-200
• Module Type: Digital I/O expansion module

Electrical Specifications:

• Digital Inputs: 16 digital inputs
  • Input Voltage: 24V DC
  • Input Current: Typically 7 mA per input
  • Input Signal Delay: 0.2 to 12 ms, configurable
  • Input Type: Sink/Source inputs (for connection to both PNP and NPN sensors)
• Digital Outputs: 16 digital outputs
  • Output Voltage: 24V DC
  • Output Current: Max 0.5 A per output
  • Output Type: Transistor (sink or source)
  • Short-Circuit Protection: Yes

Environmental Specifications:

• Operating Temperature: 0°C to +55°C
• Storage Temperature: -40°C to +70°C
• Protection Class: IP20 (suitable for indoor use)

Mechanical Specifications:

• Dimensions (W x H x D): Approx. 90 mm x 80 mm x 62 mm
• Weight: Approx. 200 g
• Mounting: DIN rail mounting or panel mounting compatible with S7-200 PLCs

Power Requirements:

• Power Supply Voltage: 24V DC
• Power Consumption: Typically 3 W

Certifications:

• CE Certified
• UL Recognized
• cULus Listed

Additional Features:

• Diagnostic LEDs: Yes, for status indication of inputs and outputs
• Compatibility: Fully compatible with S7-200 PLCs and easily integrates into existing S7-200 systems

Application:

This expansion module is used to increase the digital I/O capacity of S7-200 controllers in industrial automation systems. It is ideal for applications requiring additional digital inputs and outputs, such as machine control, process automation, and monitoring systems.
