Product Information

Experience high-quality power conversion with our 150W DC-DC Boost Converter, designed for efficiency and versatility. This non-isolated step-up module (BOOST) is capable of transforming input voltages from 10-32V to an adjustable output range of 12-35V. With a maximum output current of 6A (10A with enhanced cooling), it is a reliable solution for a variety of applications.

Key Features

• Module Properties: Non-isolated step-up module (BOOST)
• Input Voltage: 10-32V
• Output Voltage: Adjustable from 12-35V
• Output Current: 6A (10A with enhanced heat dissipation)
• Output Power: Efficiently handles up to 150W (MAX) with enhanced heat dissipation
• Compatibility: Easily drives 65W/90W dual-core notebooks

Technical Specifications

• Conversion Efficiency: Impressive 94% (measured at Input 16V to output 19V 2.5A)
• Output Ripple: Minimal at 2% (MAX) within a 20M-bandwidth
• Operating Temperature: Suited for industrial use (-40°C to +85°C); consider power adjustment or enhanced heat dissipation if ambient temperatures exceed 40°C.
• Full Load Temperature Rise: Limited to 45°C
• No-Load Current: Typical 25mA
• Voltage Regulation: Precise ±0.5%
• Dynamic Response Speed: Rapid 5% in 200uS
• Protection Features: Although short circuit protection is not included in the converter, we recommend installing fuses and protection circuits at the input port. Achieve input reverse polarity protection by using a series diode at the input port.

Precautions

Battery discharge and temperature management

The discharge voltage of a 12V battery should not be lower than 10.5V. In addition, for lithium batteries (single cell 3.7V) used in series, special attention should be paid to ensure that the discharge voltage is not lower than 2.7V. To resolve issues related to high power or high temperatures, especially when adding cabinets, we strongly recommend installing fans.

Input-Output Configuration

Correctly identify the relevant terminal marks, IN+: positive input, IN-: negative input, OUT+: positive output, OUT-: negative output. It is forbidden to connect inputs to outputs to prevent short circuits.

Range of application

1. DIY an output adjustable car power supply, only need to access your 12V power supply in the input, the output voltage you can (14-35V) free continuous adjustment,but the output voltage can not be lower than the input voltage.Power supply of vehicle-mounted notebook.The input is connected to your 12V power supply, and the output can be adjusted to the voltage of your notebook.
2. Booster charger, you can use 12V power supply to charge higher than 12V battery,such as 24V battery.
3. Power supply for your electronic equipment can work normally as long as voltage is adjusted to the voltage you need and the current does not exceed the rated current.
4.  System level power supply before, when you are doing a project when the input is 10 to 18 v, and your system board and will need about 24 v power supply and the power is large, using ordinary DC – DC module power is too small, do you choose this module will be your choice, we can g`et a job, don’t need to debug direct easily achieve high power booster.
